4.7-Inch iPhone 6 Rear Shell with Embedded Apple Logo Shown in New Photos

Earlier this month, we shared some high-quality photos and a video of what has been claimed to be the rear shell of the 4.7-inch iPhone 6 in rough form. uSwitch has now obtained a pair of photos showing the part in its completed state, revealing a polished finish and the removal of several interior physical features that had been part of the manufacturing process.

iphone_6_shell_uswitch_exterior
While the part shows a much cleaner look now that it has been polished and cleaned up, the antenna breaks at the top and bottom, previously reported to be made of a non-conductive polymer, remain quite prominent.

uSwitch primarily focuses on the shell's Apple logo, which as seen in previous leaks will change to an embedded version similar to that found on iPads rather than the printed version used in previous iPhones. The report suggests the embedded logo shown in the photos is indicative of a lighted Apple logo as has been speculated ever since the first leaks showing a cutout for the logo surfaced nearly two months ago.

iphone_6_shell_uswitch_interior
We do not, however, see any significant evidence that the logo on the iPhone 6 will be lighted. It seems more likely to us that the embedded logo is for aesthetic and/or radio transparency reasons.

Unlike the in-progress shells seen earlier this month, the finished shell also shows the full set of camera holes, including the main one for the camera itself and smaller ones for the flash and rear microphone. Consistent with previous leaks, the flash hole is round, which some have considered suspect as Apple moved to a pill-shaped flash in the iPhone 5s to accommodate the new "True Tone" dual-LED system. It is possible, however, that Apple and its partners have developed a new round version of the True Tone flash.

Related roundup: iPhone 6

Top Rated Comments

(View all)

9 weeks ago
Those bands! :eek:
Rating: 40 Votes
9 weeks ago
that white banding looks terrible :eek:
Rating: 27 Votes
9 weeks ago
When I see those antenna bands...
Rating: 17 Votes
9 weeks ago
I refuse to believe that the iPhone 6 will have those hideous antennas
Rating: 15 Votes
9 weeks ago
If this is accurate then this is just ugly with those bands.
Definitely gonna have to put a bag, I mean case over it.
Rating: 15 Votes
9 weeks ago
As with the iPhone 4 leak... people said "Look at those breaks in the steel on the side. That design is un-Apple."

Then Steve explained their existence at the keynote as being a part of the antenna system and blew us away.



I have a feeling the iPhone 6 lines contribute to some functionality that we don't know about yet. Maybe wireless charging...
Rating: 15 Votes
9 weeks ago
White banding with the black/chrome logo looks absolutely terrible.
Rating: 14 Votes
9 weeks ago
I don't believe these are genuine.

Take a look at the white bands, they do not form part of the structure of the main shell, they are simply 'stuck on'. The main metal part of the rear shell extends from end to end - so this would provide no radio-transparency - which is what the bands are designed for. Take a look at the 5S rear shell, there is a gap in the metal of the back plate at the top, providing the radio window.



My hunch - the cut-out logo will be real, and will provide the radio window the device needs. The bands - a deliberate red-herring, and will not appear on the finished product.
Rating: 14 Votes
9 weeks ago
I hope those bands are wrong!

Rating: 11 Votes
9 weeks ago
Those bands scream "knock off"....
Rating: 9 Votes
