Apple Taking Heat for Switching to Custom Screws on iPhone 4 and Portables


Kyle Wiens of repair site iFixit published a blog post today outlining Apple's increasing usage of custom "pentalobular" screws on the iPhone and other devices, with the company presumably making the shift in order to make it more difficult for users to open up their devices for repair or modification purposes.

Apple is switching to a new type of tamper-resistant screw. This is not a standard Torx, and there are no readily available screwdrivers that can remove it. This isn't the first time they've used this type of screw - it first appeared in the mid-2009 MacBook Pro to prevent you from replacing the the battery - and Apple is using a similar screw on the outer case of the current MacBook Air. This screw is the primary reason the 11" MacBook Air earned a lousy repairability score of 4 out of 10 in our teardown last October.

Apple chose this fastener specifically because it was new, guaranteeing repair tools would be both rare and expensive. Shame on them.

Wiens notes that there "isn't a single reputable supplier" offering the screwdrivers used by Apple technicians to handle the pentalobular screws.

151837 pentalobular torx screws

Apple has used the pentalobular screws in iPhone 4s sold in some international markets since the device's release, although iPhone 4s sold in the U.S. have for most of the device's history used standard Phillips screws more accessible to users. But numerous reports have surfaced from users who have taken their iPhones in for service only to discover that Apple has replaced their Phillips screws with the new pentalobular ones.

In order to assist customers interested in opening up their iPhone 4s, iFixit is offering an "iPhone 4 Liberation Kit" priced at $9.95, containing a screwdriver that will fit the new pentalobular screws (although not an exact fit), two replacement Phillips screws, and a regular #00 Phillips screwdriver.

Top Rated Comments

Rodimus Prime Avatar
130 months ago

Out of curiosity, what is a 5 point phillips head screwdriver? :p





You know exactly what I mean. It was how to descript what each point of look like.
It is a 5 point star no lobs type of screw driver. It is not standard because it is made only to take out those apple only screws.


Has to do with organic geometry. Lobe shapes and spline paths take the least amount of energy to adjust to another lobe or spline. Basic geometries take more energy and thus are not see often in nature. We continue this further, I'm going to start billing my consulting rates.



But your entire argument falls apart when low and behold inside the devices they are using standard screws. Hurts the entire argument and with machines the aligning times are not as much of an issue.
Score: 1 Votes (Like | Disagree)
oldwatery Avatar
131 months ago

This prevents a lot of illegal/unauthorized repairs from happening. It also ensures users are going to the retail stores or authorized repair centers for repair.

For each and every iPhone manufactured, i'm sure apple wants to keep a running record of all and any repairs... illegal repairs do not add to a manufactured unit's service history.

apple wants to build a flawless device. when other people are servicing the product w/o providing the manufacturer a diagnosis and repair history, apple loses this vital information. This information is extremely valuable for any kind of manufacturer.


Illegal repairs...what the hell is an illegal repair.
If I buy something I can do what the hell I want with it.
It's one thing to have the Big brother looking over my shoulder with software but hardware...give me a break.
And certainly however I chose to repair it could not be construed as illegal.
Score: 1 Votes (Like | Disagree)
nikhsub1 Avatar
131 months ago
Waiting for people to start defending this move. I mean, it's one thing to ship ALL phones with these screws but quite another to replace regular screws with these in customers phones. I would be pissed.
Score: 1 Votes (Like | Disagree)
